Rebuild Info



$322.45 to rebuild entire engine, head, injection pump, and injectors.
Here's the complete list:

Autohauz AZ
6050780581 Fuel Hose/Line; Braided Hose 3.2mm ID x 1.9mm Wall; Bulk $3.32
068130309 Fuel Hose/Line; Fuel Pipe from Filter to Pump $14.17
0009871145 Vacuum Hose/Line; Diesel Injector Overflow Line End Plug; Hose Plug $0.84
026103547 Valve Cover Oil Deflector $5.69
068109119E Timing Belt $14.43
068109243F Timing Belt Tensioner Pulley/Roller; Metal Roller $20.87
068103384A qty 10 Cylinder Head Bolt; 12x115mm total $17.40
068198012D Cylinder Head Gasket Set; Without Head Gasket $31.02
068103383AF Cylinder Head Gasket; 1.5mm 2 Groove $22.26
037198011C Block/Lower Engine Gasket Set $17.06
034105701 Connecting Rod Bearing Set; Standard with Journal Oil Holes $14.98
056198451A Main Bearing Set; Standard $37.99
068198151A Piston Ring Set; Standard 76.50mm $21.57
--Total to rebuild engine and head-- $221.60

From Bosch dealer:
0434250103 qty 4 injector nozzle total $80.40
dgk126 injection pump gasket kit $12.70
1460283312 injection pump radial seal $7.75
--Total to rebuild injection pump and injectors --$100.85
